Product Introduction
This CPU vapor chamber heat sink is composed of vapor chamber and aluminum stamped fins , and the easiest way to combine them is to soldering vapor chamber to the bottom of the stamped fin heat sink. A more efficient method is to soldering a bunch of stamped fins directly to the surface of the vapor chamber. To improve dimensional integrity, these stamped fins are usually connected to each other by locking pieces called zipper fins. And applied to Intel processor heat dissipation.
100% on-line thermal test will be performed for 1U cpu heat sink to ensure quality and cooling performance.
Pioneer Thermal Quality Assurance:
Pioneer Thermal will do the quality control from incoming material to heat sink shipped, if customer find any defect parts when received the goods, we will send replacement or credit note.
Inspection tool of Pioneer Thermal:
| Heat sink dimension | |||||
| CMM | Projector | ||||
| Heat sink performance | |||||
| Salt Spray Tester | Pressure Tester | Clip Force Tester | Drop Tester | Helium Leakage Tester | |
| Heat sink reliability | |||||
| Wind Tunnel | On Line Thermal Tester | HP Qmax Tester | HP Delta T Tester | Thermal Shock | High Temperature Aging Chamber |
Available heat sink process of Pioneer Thermal:
| Main Process | Extrusion | Bonded Fins | Skived Fins | Snapped Fins | Folded Fins | Heat Pipes |
| Cold Forging | Die Casting | FSW cold plate | Gun drill cold plate | Vacuum brazing cold plate | Vapor chamber | |
| Finishing Processes | CNC machining | Drilling | Tapping | Stamping | Anodizing | Screen printing |
| Powder coating | Laser etching | Polishing | Electrophoresis | E-coating | ||
| Finishing Value Added | Embedded fans | Thermal Greases | Screws | Springs | Clips | Embedded heat pipes |
| Phase change materials | Back plates | Gap filler pads | PEMs | Standoffs | Dielectric pads | |
| Compounds | ||||||
Pioneer Thermal R&D:
Our seasoned professionals can model and critique the thermal implications of your design using Icepak, Flotherm, CFD, Solidworks, ProE, and AutoCAD. We can manage your thermal needs from the conceptual design stage, through prototypes and into production, which enable us to be your “one-stop” shop for quality thermal solutions, delivered on time and at competitive prices.
About Pioneer Thermal:
As a heat sink manufacturer in China, Pioneer Thermal is certified with ISO9001, ISO14001 and TS16949 with 7500 square meter facility, and has a dedicated quality assurance department with full CMM capabilities. We are focused on providing advanced technology, superior customer service and outstanding value to our industry partners.
